Raspberry Pi 5 – 2GB / 4GB / 8GB / 16GB LPDDR4X

Experience the next generation of computing with the Raspberry Pi 5 — a major leap in performance, connectivity, and capability. Built around a 64-bit quad-core Arm Cortex-A76 processor running at 2.4GHz, the Raspberry Pi 5 delivers up to 3× faster performance compared to the Raspberry Pi 4.

Powered by the all-new RP1 I/O controller, designed in-house by the Raspberry Pi team, this model redefines desktop performance and opens up new possibilities for embedded and industrial applications alike. Whether you’re creating smart devices, developing IoT systems, or using it as your daily desktop computer — Raspberry Pi 5 is ready for anything.

Key Highlights

• 2–3× CPU Performance Boost: Quad-core Arm Cortex-A76 @ 2.4GHz for blazing-fast multitasking and application performance.
• New RP1 Southbridge: Designed by Raspberry Pi, the RP1 chip delivers massive improvements in I/O and peripheral handling.
• Enhanced Graphics: 800MHz VideoCore VII GPU with support for dual 4Kp60 HDMI displays and HDR output.
• Re-engineered Camera & Display Interface: Dual 4-lane MIPI CSI/DSI connectors with flexible camera/display configurations.
• Wide Memory Options: Available in 2GB, 4GB, 8GB, and 16GB LPDDR4X-4267 SDRAM variants.
• Improved Connectivity: Dual USB 3.0 ports, dual USB 2.0 ports, Gigabit Ethernet, Wi-Fi 802.11ac, and Bluetooth 5.0.
• PCIe 2.0 Support: Expand your system with add-on HATs for SSDs and high-speed peripherals.
• Integrated Real Time Clock (RTC), Power Button, and Fan Connector.

Processor & Performance

• CPU: 64-bit Quad-Core Arm Cortex-A76 @ 2.4GHz
• Hardware AES Cryptographic Extension support
• 512KB L2 cache per core
• 2MB shared L3 cache

The upgraded architecture ensures smoother multitasking, faster code execution, and optimized performance for modern applications.

Display & Graphics

• Dual 4Kp60 HDMI display output with HDR
• VideoCore VII GPU supporting OpenGL ES 3.1 and Vulkan 1.2
• Hardware 4Kp60 HEVC decoder for ultra-clear video playback
• Enhanced Image Signal Processor (ISP) for high-quality camera imaging

Connectivity Options

Power Requirements

• Recommended Power Supply: 5V / 5A DC (Official Raspberry Pi 27W USB-C Power Supply)
• Minimum: 5V / 3A DC (peripheral current limited to 600mA)
• Connector Type: USB-C

Important Power Note:

Use only the official Raspberry Pi 5 27W USB-C Power Supply. It includes USB-PD support and ensures your board receives stable 5A at 5V.
Using non-compliant chargers (especially mobile USB-PD adapters) may cause limited current availability or system instability.

Dimensions

• Size: 85mm × 56mm
• Form Factor: Standard Raspberry Pi layout, compatible with existing HATs and accessories.

Important Compatibility Notice

• Raspberry Pi 5 does not support Windows OS.
• Compatible operating systems include Raspberry Pi OS (Bookworm or later) and other Linux-based distributions.
• Returns will not be accepted solely for OS incompatibility issues.

Power Supply Recommendation

For best performance, use the official Raspberry Pi 5 27W USB-C Power Supply.
It ensures the correct voltage and current delivery with USB-PD protocol support, protecting your device and peripherals.

What’s New in Raspberry Pi 5

• Perfect for desktop computing, edge AI projects, IoT applications, and DIY electronics.
• Faster, smarter, and more capable than ever before.
• Supported by a massive community, documentation, and accessory ecosystem.

Bring your ideas to life with the all-new Raspberry Pi 5 — the fastest, smartest, and most powerful Raspberry Pi yet.
